Potentiometer law modelling and identification for application in physics-based Virtual Analog circuits

This is the companion webpage for the 22nd International Conference on Digital Audio Effects paper “Potentiometer law modelling and identification for application in physics-based Virtual Analog circuits” by Ben Holmes and Maarten van Walstijn.

Contents

1. Additional material for modelling Alpha Potentiometers

1.1. Linear-cubic Piecewise Function

MATLAB code for creating a linear-cubic piecewise function.

1.2. Explicit solution to the cubic sub-function

1.3. Modelling Alpha laws with a linear-cubic piecewise function

Plots and transitional values for the linear-cubic piecewise functions to model specified and measured characteristics from Alpha. Download the measured potentiometer characteristics for both linear and logarithmic potentiometers here.

2. Big Muff Pi tonestack identification

2.1. Big Muff Pi tonestack model

MATLAB code to find the transfer function of the Big Muff Pi tonestack.

2.2. Big Muff Pi tonestack measurements

Measurement data collected from a breadboarded circuit of the Big Muff Pi tonestack.

2.2. Multisine excitation signal

MATLAB code for generating the multisine excitation signal used in the measurement of the Big Muff Pi tonestack.

Bibliography extension

The latest potentiometer specification from the U.S.A. Department of Defense, MIL-R-94 G amendment 1, can be found here.

My doctoral thesis as referenced in the paper can be found here. This document is subject to change.
